Radalert100 multi function radiation detector
Radalert100 alpha, beta, gamma and X multifunctional radiation detector is a new general Geiger counter for the determination of alpha, beta, gamma and X-ray radiation. LCD digital display readings, can be selected per minute count (CPM), mR/hr (or HR SV/) and cumulative count, up to 350000 CPM or 110.0mR/h. Every time the count with red LED flash and beep prompt. When the radiation reaches the level that the user is automatically set, the instrument automatically sends out sound and light alarm. This product is in line with the requirements of the European CE certification.
Application domain:
The monitoring of personal exposure to radiation
The monitoring area or perimeter
The monitoring of radiation leakage and pollution
- ensure compliance with the provisions of the management department
The changes of monitoring background radiation
The principle of nuclear physics demonstration
The radiation of minerals
The working principle of the instrument:
Each time the ray passes through the Geiger tube and causes ionization, the Geiger counter generates a pulse of current. Each pulse is an electronic probe and operation. The detector is calculated in the mode you select: CPM, mR/hr, or total. In S1 units, the use of CPS and sv/hr. The number of counts detected by the detector is changed every minute due to the arbitrary state of the radioactive energy. In the past period of time the average value is more accurate, and this period of time the longer the more accurate data.
Technical index:
The dose rate: 0.001-110.0mR/hr or 0.01-1100 SV/ HR
The count: the total number of CPM:0-350000 or CPS:0-3500: 1-9999000
The typical value of accuracy: 10% 15% maximum (mR/Hr and SV/ HR mode)
The timer: 40 hours
The sensitivity of reference: 1000cpm/mR/Hr, Cs137
It shows that: four digit liquid crystal display, containing mode indication
The built-in alarm: when the radiation level reached the preset value when the sound alarm;
User adjustable alarm level up to 50mR/Hr and 160000CPM
The count of LED lights flashing lights: every count
Her voice: every time the count a BP like voice, mute
The power: 9V alkaline battery, the general background levels available for 2160 hours; 1mR/Hr mute when available 625 hours
The options: cable and software
- size: 150 x 80 x 30mm
The weight (g): 225g
The certification: CE
